Description
FEATURES
| Burner – Right Rear | 18,000 BTU |
| Fuel Type | Natural Gas |
| Dishwasher Safe Knobs | Yes |
| Control Location | Upfront |
| Cooktop Type | Continuous Grates |
| Burner – Left Rear | 18,000 BTU |
| Automatic Re-Ignition | Yes |
| Cooktop Burner Grate Material | Heavy Cast |
| Burner – Right Front | 10,000 BTU |
| Configuration | 6 Burners |
| 140 Deg. Simmer Burner | All Burners – Adjustable |
| Control Type | Manual Simmer (1-9) Hi |
| Burner – Left Front | 21,000 BTU Multi-ring Burner |
| Burner – Center | 12,000 BTU Front / 12,000 BTU Rear |
| Extra Low Simmer | All Burners – Adjustable |
| Valves (Degree of Turn) | 270 |
| Ignition System | Electronic w/Auto Reignition |
| Cooktop Surface | |
| Cooktop Burner Grate Features | Continuous Grates Dishwasher Safe Matte Black Porcelainized Cast Iron |
| Product Type | Rangetop |
APPEARANCE
| Color Appearance | Stainless Steel |
| Control Knobs | Brushed Stainless Dishwasher Safe Professional-Style |
| Design Style | Professional |
WEIGHTS & DIMENSIONS
| Cutout Height (in) | 8 |
| Cutout Depth (in) | 25.25 |
| Approximate Shipping Weight | 163 |
| Cabinet Width | 36.000000 |
| Net Weight | 135 |
| Overall Depth | 27.5 |
| Overall Width | 35.875 |
| Overall Height | 8.5 |
| Cutout Width (in) | 35 |
POWER / RATINGS
| Burner BTU Ratings (000’s/BTU) – LP Gas | (1) 18.0; (2) 15.0; (2) 12.0; (1) 9.1 |
| Volts/Hertz/Amps | 120v; 60Hz; 15A |
| Hertz | 60 |
| Burner BTU Ratings (000’s/BTU) – Natural Gas | (1) 21.0; (2) 18.0; (2) 12.0; (1) 10.0 |
| Electrical Requirements | 120V |
ACCESSORIES
| High Altitude Kit | Natural Gas: WB28X39728; LP: WB28X39729 |
| Factory-installed island backguard | Yes |
| Optional Backguard | 12″ stainless steel backsplash (UX12B36PSS) 30″-36″ adjustable stainless steel backsplash with warming shelf (UXADJB36PSS) |
| Conversion Kit | Included – Nat. Gas to LP |
| Reversible Griddle/Grill Accessory | UXPRRGG |
| Optional Kits | CXPR6HKPTBT Brushed Black CXPR6HKPTBZ Brushed Bronze CXPR6HKPTCG Brushed Brass CXPR6HKPTCU Brushed Copper CXPR6HKPTFB Flat Black CXPR6HKPTSS Brushed Stainless |
| Griddle Cover | WB34X39889 |
WARRANTY
| Parts Warranty | Limited 1-year entire appliance |
| Labor Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
CERTIFICATIONS
| Claims & Certifications | ADA Compliant California Prop 65 CSA View Chemical Content Reports |
